Specification
flow | Origin | Working Pressure | Dimensions | Temperature resistance | Inlet/Outlet Size |
210ml/min | Made in China | <0.5MPa | Ø61*274m mØ61*282mm | <45℃ | 1/4inch |
Housing Specifications | |||
material | Processing methods | Assembly method | Shell under pressure |
Food-grade Polypropylene (PP) | Injection Molding | spin welding | > 3.5 Mpa |
Test Conditions The permeate flow and salt rejection are based on the following standard test conditions | |||
Feed Water | Recovery Rate | Applied Pressure | Permeate Flow Variation |
250 ppm softened tap water | 15% | As rated above | Individual element flow may vary by±20% |
Filter Media Specifications | |||||
Applied Pressure | Permeate Flow Rate | Min. Salt Rejection ($Cl^-$) | Stabilized Salt Rejection ($Cl^-$) | Diaphragm Type | Maximum operating temperature |
50 psig (3.4 bar) | 50 gpd (7.9 L/h) | 95% | 96% | Polyamide Thin-Film Composite (TFC) | 113°F ( 45 C ) |
Maximum operating pressure | Maximum water flow | pH Range (Continuous Operation) | Maximum Feed Silt Density Index (SDI) | Free Chlorine Tolerance | |
300psig( 21bar ) | 2.0gpm( 7.6lpm ) | 2-11 | SDI 5 | < 0.1 ppm | |
Skip the middlemen and trading companies on B2B platforms. We are the source, ensuring the most competitive wholesale prices for your business.
Unlike random sellers on marketplaces, we offer long-term, consistent quality and stock availability.
We don't just sell products; we build your brand. Custom specifications and private labeling are our core strengths.
Speak directly with our technical team who understands water filtration inside out, not just a generic sales agent.
We have professional R&D ability to meet market demand
